Optrel e3000X PAPR System with Vegaview Helmet (4580.051)
The Optrel e3000X PAPR system is paired with their innovative HEPA class three filter that blocks more than 99.8% of particulates for increased safety. The Optrel e3000 PAPR provides maximum protection against exposures to smoke, dust, and other particulates. It's lightweight design and easy to access buttons make wearing it a pleasure.
Respiratory Protection – The e3000’s innovative HEPA class Th3 filters blocks more than 99.8% of particulates for increased safety. Its face seal prevents welders from being exposed to smoke and other debris when working.
Two-Channel Air Distribution – Its unique internal design presents clean air to the mouth and nose, and to the forehead for cooling, improving overall comfort while reducing fatigue over time. Welders can adjust to three levels of air flow depending on environmental needs or personal comfort preferences (200 to 240 nl/min).
Ergonomically Designed – The e3000’s belt-based blower unit sits comfortably at the welder’s center of gravity, with easy access buttons to control the unit. Its hose connections on the helmet and blower swivel to ensure full range of movement, reducing the potential for tangling or snagging on surrounding structures.
Enhanced Productivity – Integrated flow sensors perform an automatic air flow check at start up, eliminating the need for welders to manually check their system each time of use. Plus, its rechargeable battery operates up to 12 hours continuously without replacement.
Audible Alarms – Audible and visible alarms alert welders of a missing or clogged filter, and when the battery is running low.
Maximum Protection – Provides maximum protection from exposures to smoke, dust, and other particulates, including Hexavalent chromium (CrVI).
PAPR Quick Specs
• NIOSH Certification - P100 (42 CFR 84)
• Filter - HEPA Class Th3
• Air Flow - 3 Levels (200 – 240 nl/min)
• Blower Unit Weight - 3.5 lbs (including filter, belt and battery)
• Battery – Li-Ion rechargeable (approx. 12 hours of continuous use per full-charge)
Includes
• Vegaview 2.5 Welding Helmet
• Blower Unit with Hose and Belt
• Protection Sleeve
• TH3P R SL Filter
• Battery and Battery Charger
• Instruction Manual
• 2 Year Mfg Warranty (no battery warranty)
Respiratory Protection – The e3000’s innovative HEPA class Th3 filters blocks more than 99.8% of particulates for increased safety. Its face seal prevents welders from being exposed to smoke and other debris when working.
Two-Channel Air Distribution – Its unique internal design presents clean air to the mouth and nose, and to the forehead for cooling, improving overall comfort while reducing fatigue over time. Welders can adjust to three levels of air flow depending on environmental needs or personal comfort preferences (200 to 240 nl/min).
Ergonomically Designed – The e3000’s belt-based blower unit sits comfortably at the welder’s center of gravity, with easy access buttons to control the unit. Its hose connections on the helmet and blower swivel to ensure full range of movement, reducing the potential for tangling or snagging on surrounding structures.
Enhanced Productivity – Integrated flow sensors perform an automatic air flow check at start up, eliminating the need for welders to manually check their system each time of use. Plus, its rechargeable battery operates up to 12 hours continuously without replacement.
Audible Alarms – Audible and visible alarms alert welders of a missing or clogged filter, and when the battery is running low.
Maximum Protection – Provides maximum protection from exposures to smoke, dust, and other particulates, including Hexavalent chromium (CrVI).
PAPR Quick Specs
• NIOSH Certification - P100 (42 CFR 84)
• Filter - HEPA Class Th3
• Air Flow - 3 Levels (200 – 240 nl/min)
• Blower Unit Weight - 3.5 lbs (including filter, belt and battery)
• Battery – Li-Ion rechargeable (approx. 12 hours of continuous use per full-charge)
Includes
• Vegaview 2.5 Welding Helmet
• Blower Unit with Hose and Belt
• Protection Sleeve
• TH3P R SL Filter
• Battery and Battery Charger
• Instruction Manual
• 2 Year Mfg Warranty (no battery warranty)
| MPN: | OPT4580.051 |
|---|---|
| UPC: | 640127616000 |
| Warranty | 2 years with additional 1 year warranty extension (excluding battery) if the product is registered within the first 6 months: |
| Arc Sensors | 3 sensors, variable detection angle with movable sensor slider |
| Delay Control | Light to dark: 0.100 ms at room temperature 0.070 ms at 55°C / 131°F Dark to light: from 0.05 s to 1.0 s adjustable |
| Digital | Ultraviolet-/infrared protection (maximum at any shade setting) Infinite exterior shade level setting Visible range activated: shade level 8 – 12 Visible range not activated: shade level 2.5 |
| Grind Mode | Optical class: 1 Scattered light: 1 Homogeneity: 1 Angular dependence:2 |
| Modes | 2 pcs batteries 3V exchangeable (CR2032) |
| Reaction Time | Light to dark: 0.100 ms at room temperature 0.070 ms at 55°C / 131°F Dark to light: from 0.05 s to 1.0 s adjustable |
| Sensitivity Control | Light to dark: 0.100 ms at room temperature 0.070 ms at 55°C / 131°F Dark to light: from 0.05 s to 1.0 s adjustable |
| Viewing Field | Ultraviolet-/infrared protection (maximum at any shade setting) Infinite exterior shade level setting Visible range activated: shade level 8 – 12 Visible range not activated: shade level 2.5 |
MPN: OPT4580.051
UPC: 640127616000
